Description
Technical Specifications
| Material | Aluminum profile, iron grey, fanless design |
| Processor System | Intel alder lake-N series processors, N100/N305, TDP15W EFI BIOS |
| Memory | 1 x DDR5 SO-DIMM, total maximum 16 GB |
| Storage | 1 x M.2 M-Key 2280 (PCIe3.0 2X protocol), 1x SATA3.0, 2Pin 5V power supply |
| RAM Socket | 1 x DDR5 SO-DIMM, max up to 16GB |
| Lan Port | 4 x 2.5 G LAN |
| Display | 1 x HD2.0 interface, 1*DP1.4 interface, support 4K 60 Hz type-C interface, supports DP 4 K60 Hz and USB 3.2 Gen2 |
| External I/O Interface | 2 x USB3.0, 2 x USB2.0, TF card, DC JACK, HD+DP, type-C 4 x 2.5G LAN (3 x intel i226-V, 1 x RTL8156B, optional POE 48 V and 15 W), RJ45 console |
| Expansion Interface/Function | External TPM2.0 is optional, N/A by default, the default is CPU built-in TPM2.0 1x miniPCIe ( PCIe+USB2.0+SATA3.0 protocol, WIFI/BT/mSATA/4G ) No SIM card by default, 5 x RS232/RS485 pin headers (hardware selection ) 8 x GPIO |
| Power Supply | DC 12 V, 36 W or above |
| Operating System | Win10, win11, linux |
| Working Temperature | -4°F to 140°F (-20 ℃ to +60 ℃) |
| Storage Temperature | -40°F to 185°F (-40 ℃ to +85 ℃) |
| Working Humidity | 5% to 90% |
| Storage Humidity | 5% to 90% |
| Product Size | 9.45 in × 8.66 in × 3.09 in (240 mm x 220 mm x 78.5 mm) |
| Weight | 5.51 lbs (2.5 Kg) without packaging |
