Description
Technical Specifications
| Case Size | 3.15 × 2.56 × 1.5 in (80 × 65 × 38 mm) |
| Probe Size | 1.65 × 0.63 in (42 × 16 mm) |
| Power Consumption | 60mA |
| Resolution | Temperature: 0.1°F (0.1°C), Humidity: 0.1% RH |
| Entry Connector | M16 × 1.5 mm |
| Output Type | 4 to 20mA, 0 to 10VDC, RS485 |
| Temperature Range | -40°F to 158°F (-40°C to 70°C) |
| Humidity Range | 0 to 100% RH |
| Power Supply | DC 9V to 24V |
| Communication Protocol | RS485, Modbus-RTU |
| Measurement Accuracy | Temperature: ±0.3°F (±0.2°C), Humidity: ±2% RH |
