| CPU |
J1900, J6412, J6413, i3, i5, i7 |
| Memory |
Supports 4GB to 64GB (laptop memory) |
| Storage |
1 x M.2 2280 M-key |
| Network |
2 x 1000Mbps RJ-45 Ethernet interface |
| Audio |
Realtek ACL662 audio controller |
| USB |
4 x USB3.0, 4 x USB2.0 (internal) |
| Serial Port |
4 x RS-232; 1 x RS-232, RS-485 |
| Expansion Slot |
1 onboard M.2 2242, 50 B-Key slot, support 4G, 5G; WIFI wireless network card |
| Rear IO Interface |
1 x DP, 1 x HDMI, 2 x GLAN, 4 x USB, Line-0ut, Mic-in, DC-IN |
| Operating System |
Windows 10, Linux |
| Input Voltage |
Support 9 to 36V DC |
| Screen Type |
17.0 inch (43.18 cm) Full HD TFT |
| Resolution |
1280 x 1024 |
| Backlight MTBF(Hour) |
30000 HRS |
| Pixel Pitch |
0.294 X 0.294 |
| Contrast |
800:1 |
| Viewing Angle |
(L)85 or (R)85 or (T)80 or (B)80 |
| Transmittance |
＞95% |
| Controller |
USB interface |
| Driver Support |
Windows 10, Linux |
| Response Time (For Touch Pens) |
＜5ms |
| Surface Hardness |
Moh’s hardness 7H |
| Touch Lifespan |
250g or 35,000,000times |
| Stroke Lifespan |
250g or 5,000,000times |
| Vibration During Operation |
SSD applied: 1.5Grms, 5 to 500Hz, 1hr or axis |
| Shock During Operation |
SSD applied: 10G, half sine wave |
| Backlight |
LED |
| Touch Screen Type |
10-point capacitive touch screen |
| Relative Humidity |
10 to 95%RH@40°C, non-condensing |
| Temperature Operating |
(0 to 45°C) 32 to 113°F, (0 to 50°C) 32 to 122°F (using a solid-state drive rated for standard temperature levels), (-20 to 60°C) -4 to 140°F (using a wide temperature range solid-state drive) |
| Temperature Storage |
(-20 to 60°C) -4 to 140°F |
