| Processor Type |
AMD Ryzen 7 |
| Graphics |
Integrated or NVIDIA Quadro T1000 with 256 MB VRAM |
| System Memory |
1 slot, supports up to 8 GB DDR3L |
| Storage |
HDD (4200 rpm), mSATA and 2.5-inch SATA support |
| Operating System |
Windows XP, 7, 8, 10, WES 7, Linux |
| Display Size |
8.0 inch |
| Display Resolution |
800 x 600 |
| Display Type |
TFT LCD, 4:3 aspect ratio |
| Response Time |
2 ms |
| Viewing Angle |
178° |
| Touch Screen |
Projected capacitive or 5-wire resistive |
| Touch Durability |
Up to 50 million touches (capacitive) or 35 million touches (resistive) |
| Brightness |
250 cd/m² |
| Network |
Dual Gigabit Ethernet ports, Wi-Fi |
| USB Ports |
3x USB 2.0, 1x USB 3.0 |
| Serial Ports |
4x COM (RS-232 or RS-485) |
| Video Ports |
HDMI, VGA, DP, AV, BNC |
| Expansion |
Mini-PCle slot with SIM support |
| Audio |
Line-out, optional amplifier output, audio input/output |
| Other Interfaces |
GPIO, aviation, LPT |
| Optical Drive |
CD-ROM |
| Input Power |
DC 12 V, wide voltage support |
| Switch |
Yes |
| Watchdog Timer |
Programmable, 1 to 255 seconds |
| Ingress Protection |
IP65 (Waterproof and dustproof) |
| Environmental Resistance |
Dust, grease, wet location, marine, vehicle, high/low temperature, highlight, electromagnetic interference |
| Mounting |
VESA 75, panel mount |
| Material |
Aluminum |
| Product Color |
Black |
| Operating Temperature |
14°F to 140°F (-10°C to 60°C) |
| Storage Temperature |
-22°F to 158°F (-30°C to 70°C) |
| Operating Humidity |
10% to 90% RH at 86°F (30°C), non-condensing |
| Product Dimensions |
8.61 in x 6.99 in x 2.03 in (218.6 mm x 177.5 mm x 51.7 mm) |
| Product Weight |
3.53 lb (1.6 kg) |
