| Processor Core |
Octa Core |
| Support Resolution |
8K |
| WIFI |
802.11n 2.4G or 5 GHz |
| Resolution |
1080P |
| Operation System |
Android 12.0, DEBIAN11, Ubuntu 20.04 |
| Ethernet |
1 x 10 or 100 MBps or 1000 MBps |
| Keyboard |
No |
| Private Mold |
Yes |
| CPU |
RK3588 |
| GPU |
Mali-G610 GPU，OpenGL ES 1.1 or 2.0 or 3.2，OpenCL 2.2，Vulkan 1.2 |
| OS |
Android 12 or Ubuntu or Linux |
| RAM |
4 GB or 8 GB or 16 GB |
| ROM |
32 GB or 64 GB or 128 GB |
| HD Video Ouput |
Ultra HD 8K at 60 fps, HD 2.1 |
| USB Ports |
1 X USB3.1, 2 X USB2.0, 1 X Type C3.1 |
| Other Interfaces |
1 X HD 50.8 mm (2.0 in ),1 X HD 2.1 Out,1 X DP 1.4,2 X Ethernet Ports |
| Network |
2.4G or 5G Dual band WiFi6 + 1000M Ethernet |
| BT |
BT V5.1 |
| Chipset |
RK3588 Octo-core, Cortex-A76 and Cortex-A55 |
| Type C |
USB3.1 OTG Type-C X 1 |
| LAN |
Ethernet:10 M or 100 M or 1000M standard RJ-45 : 2 X Lan ports |
| Wireless |
IEEE 802.11a or b or g or n or ac or ax MIMO 2.4G or 5G dual-band Wifi6 |
| Power supply |
INPUT：100 V to 240 V 50 Hz or 60 Hz OUTPUT:DC 12V or 3A |
| Display Port |
1 X HDMI In, 1 X HDMI2.1 Out, 1 × DP1.4, |
| 4G |
Mini Pcie and Nano SIM card |
| SATA |
SATA 3.0 7Pin X 1 |
| Audio Output |
1 X 0.03 in (3.5 mm) headphone audio port . 1 X MIC |
| Industrial Interface |
1 X URS232; 1 X RS485 X ; 1 X I2C X 1; 6 X GPI0 X 6 |
| OSD type of languages |
English |
| Operating Temperature |
14 °F to 113 °F (-10 ℃ to 45℃) |
