| Function |
SNMP, VLAN Support |
| WAN Ports |
1 |
| Throughput |
1.44 Tbps |
| Network |
Wireless Lan, Wired LAN, ONVIF, SDK, TCP |
| Traffic Analysis |
NetStream |
| VLAN |
Adding access, trunk, and hybrid interfaces to VLANs/Default VLAN |
| Storage Altitude |
16404.20 ft (< 5000 m) |
| MTBF [year] |
112.71 |
| MTTR [hour] |
0.5 hour |
| Availability |
0.999999494 |
| Redundant Power Supply |
1+1 |
| Maximum Number Of Physical Ports On The Entire Device |
120 |
| Noise At Normal Temperature (acoustic power) |
< 72 dB (meeting the ETSI 72 dBA standard) |
| Power Supply Mode |
AC |
| Input Voltage Range [V] |
90 V to 290 V |
| Rated Input Voltage [V] |
200V to 240V/100V to 127V dual live wires, support 240V HVDC |
| Maximum Input Current [A] |
10 A |
| Rated Output Power [W] |
1500 W |
| Number Of Service Board Slots |
6 |
| Number Of Slots |
11 |
| Airflow Direction |
From left to right |
| Maximum Input Cable Size |
Standard C13 cable |
| Front-End Circuit Breaker/Fuse |
≥10 A |
| Restriction On The Operating Temperature Variation Rate |
≤ 0.5°C/min (32.9°F/min), non-condensing |
| Long-Term Operating Temperature |
-4 °F to 131 °F (-20 °C to 55 °C) |
| Storage Temperature |
–40 °F to +158 °F (–40 °C to +70 °C) |
| Dimensions (H x W x D) |
3.5 in × 8.66 in × 17.4 in (44.2 cm x 22.0 cm x 4.4 cm) |
| Operating Temperature |
32 °F to 104 °F (0 °C to 40 °C) |
