| Transmission Distance |
Max 984.25 feet (300 m) |
| Communication Methods |
Ethernet, Optical fiber, Wi-Fi, 4G, 5G (Optical) |
| Industrial Communication Interface |
RS458 |
| Communication with Sensor |
Zigbee: 1.4 GHz IEEE 802.15.4 |
| IP Grade |
IP66 |
| Shell Material |
Cast aluminum |
| Maximum Number of Supported Sensors |
60 pcs |
| Maximum Channels (Optional) |
8 channels, 16 channels, 24 channels |
| Channel Number |
24 channels |
| Sensor Integrated |
IEPE acceleration sensor, High/low frequency and dual acceleration acquisition synchronously |
| Input Impedance |
750kΩ |
| Input Coupling |
AC |
| Sensor Drive Current |
4 mA to 24 V |
| A/D Converter |
24 bits delta-sigma ADC |
| Sampling Frequency |
51.2 Hz, 165 Hz, 512 Hz, 1289 Hz, 2560 Hz, 5120 Hz, 12.8 KHz, 25.6 KHz, 51.2 KHz |
| Dynamic Range |
114 dB |
| Signal Input Range |
0 V to 24 V |
| Weight |
About 5.51 lb. (2.5 kg) |
| Ambient Temperature |
-40 °F to 158 °F (-40 ℃ to 70 ℃) |
| Storage |
-58 °F to 185 °F (-50 ℃ to 85 ℃), non-condensable |
