Description
Features
- Multiple level network options
- Event-triggered data uploads
- Two-way communication protocol
- Transparent of data transmission
Technical Specifications
| Wireless Network | Gsm/Gprs (Optional 3g, 4g) or Wifi |
| Ethernet | 1 port RJ45, 10M/100M Adaptive |
| Digital Input | 4 Channels |
| Digital Output | 2 Channels |
| Analog Input | 8 Channels, 4-20mA |
| Series Port | 1 RS232 & 1 RS485 |
| Protocol | Modbus, http Post, CWTIO |
| Working Environment | -22 ℉ to 158 ℉ (-30 ℃ to +70 ℃) / 5 to 95%(non-Condensing) |
| Dimension | 5.11 in x 3.18 in x 0.98 in (13 cm x 8 cm x 2.5 cm) |
