Description
Features
- RS232, RS485, analog/digital inputs, relay outputs, power I/O
- Works with flowmeters, pressure, water quality, PLCs, etc
- Supports 4G/3G/2G, LTE CAT M1/NB-IoT
- Modbus RTU/TCP, MQTT, JSON, TCP/UDP
- Sync up to 5 centers, 16MB local storage
- User-friendly setup and debugging tools
- Sleep modes, scheduled data collection, auto reporting
- Control via SMS, commands, software, DMP1
Technical Specifications
| Serial Port | 2x RS232, 1x RS485 |
| Analog Input | 3x Analog input (4-20 mA, or 0-5 V) |
| Digital Input (DI) | 2x Digital input |
| Digital Output (DO) | 2x Relay output |
| Power Output | 1x Power output (12 V, 1 A) |
| Power Input | 5-35VDC |
| Data Storage | 16MB |
| Protocols | MQTT, Modbus RTU |
| Mounting | Din-rail or Wall mount |
