| Theory |
Temperature and Vibration Sensing |
| Output |
RS485/4-20mA/0-5V/0-10V/WIFI/LORA |
| Voltage Supply |
DC10-30V or 3.6V Lithium Sub-Battery |
| Mounting Type |
Thread, Magnetic, or Adhesive Installation |
| Resolution |
0.1°C Temperature, 0.1 mm/s Vibration Velocity |
| Frequency Range |
10 Hz to 1600 Hz, 10 Hz to 5000 Hz |
| Vibration Speed Range |
0 to 50 mm/s |
| Vibration Speed Accuracy |
±1.5% FS (@1kHz, 10mm/s) |
| Protection Class |
IP67 |
| Customized Support |
OEM, ODM |
| Measuring Direction |
1-Axis or 3-Axis |
| Surface Temperature Range |
-40 °F to 176 °F (-40 °C to 80 °C) |
| Operating Temperature |
-40 °F to 176 °F (-40 °C to 80 °C), 0 to 80% RH |
| Features |
Stainless Steel Build |
| Size / Dimension |
6.3 in x 6.3 in x 3.1 in (16 cm x 16 cm x 8 cm) |
