Description
Overview
Asset Track Pro Iridium GPS Tracker with Remote Monitoring for Mining Applications is a GPS locator for boat, ship and vehicle. It has iridium SBD transceiver, which provides globe service, supplies satellite communications. The product is waterproof grade up to IP67, it provides superior sensitivity GPS application. The device could be monitored by backend server or other specified terminals and it has one input and one output interfaces that can be used to monitor vehicle status or control external device.
Features
- Iridium SBD transceiver, Truly Globe coverage
- High sensitivity -165 dBm (Tracking), Fast TTFF
- Location report compressed into 10 bytes, saving data costs.
- ACC detection
- remote engine cutoff/restart
- Embedded 3D accelerate sensor
- Waterproof IP67
- 500Mah backup battery
- Firmware update over the air
Technical Specifications
| Parameters | Description |
| Data transmission | Iridium SBD satellite communication, SMS, email |
| Operating voltage | 8 V to 32 V DC |
| Maximum operating power | < 450 mA to 13.8 V (transient peak current: 2 W) Network communication protocol, embedded TCP, IP protocol stack, support TCP, IP |
| Iridium Frequency | 1616 MHz to 1626.5 MHz |
| Iridium downstream data | Maximum length 195 mA |
| Transmit power | 1.6 W |
| Sensitivity | -165 dBm |
| Battery | Li-Po 3.7V 500 mAh |
| Operating Temperature | -4°F to 140°F (-20°C to 60°C) |
| Dimension | 3.94 in x 2.72 in x 1.61 in (10 cm x 6.9 cm x 4.1 cm) |
| Weight | 3.6 oz (102 g) |
