| Parameters |
Description |
| Network |
GSM, GPRS |
| Supported Bands |
850, 900, 1800, 1900 MHz |
| GPS Chip |
UBLOX-7020 |
| GSM Module |
MTK 6260D |
| GPS Sensitivity |
-159 dBm |
| GPS Accuracy |
16.4 ft (5 m) |
| Time to First Fix |
Cold Status: 45 s to 120 s, Warm Status: 35 s, Hot Status: 1 s |
| Battery Type |
Non-rechargeable 5000 mAh dry battery |
| Standby Time |
3 years |
| Tracking System |
Accessible via web and mobile app |
| LED Indicators |
2 LEDs to display GPS and GSM status |
| Certificate |
CE ROHS |
| Use Cases |
Automotive, tools, child safety, asset tracking, fleet management |
| Humidity |
5 % to 95 % non-condensing |
| Temperature |
-4 °F to 131 °F (-20 °C to 55 °C) |
| Dimensions |
3.03 in x 1.57 in x 0.83 in (7.7 cm × 4.0 cm × 2.1 cm) |
| Weight |
4.69 oz (133 g) |
