| Chip |
Impinj R2000 |
| Spectrum Range |
860 MHz to 960 MHz (customized optional) |
| Protocol |
EPC global Class1 Gen2, ISO 18000-6C |
| Transmission Mode |
FHSS or fixed frequency, Support RSSI |
| RF Output Power |
33 dBm |
| Operating Modes |
Passive mode, real-time inspection mode |
| Anti-Collision Modes |
Supports EPC, TID, USER, EPC+TID |
| Peak Inventory Speed |
>700 tags per s |
| Tag Buffer Size |
1000 tags at 96 bits EPC |
| Data Operations |
Supports EPC and TID area data read/write |
| Power Supply |
Single +12V power supply, optional POE |
| Communication Interfaces |
RS232, USB, RJ45 (TCP/IP), WIFI (optional), 4G (optional), POE (optional) and others |
| I/O Control |
2 channels of input control (5V signal), 2 channels of output control (5 V signal), 2 channels of relay control |
| Software Support |
Free Windows, Linux & Android DEMO software and SDK for testing and development |
| SDK |
Supports X86 & X64, C++, C#, VB, Delphi, Linux, ARM, Python, NodeJS, QT, JAVA, Android |
| Temperature Sensor Support |
Supports temperature sensor RFID tag and the normal RFID tag |
