| Enclosure |
IP67/NEMA-6 industrial-grade with cable glands |
| Power Supply |
PoE (802.3af) with Surge Protection |
| LoRa Concentrators |
Dual concentrators for up to 16 channels |
| Backhaul |
Wi-Fi, LTE, and Ethernet |
| GPS |
Supported |
| Power Options |
DC 12V or Solar power supply with electricity monitoring (Solar Kit optional) |
| Antennas |
Internal antennas for Wi-Fi, GPS, and LTE; External antenna for LoRa |
| Dying-Gasp |
Optional |
| Chipset |
mt7628 |
| Applications |
LoRaWAN solutions, Water Meter AMR system |
| Network Server |
Built-in Network Server |
| VPN Support |
OpenVPN |
| Software/UI |
Built on OpenWRT |
| LoRaWAN Version |
LoRaWAN 1.0.3 |
| LoRa Frame Filtering |
Node whitelisting |
| MQTT |
MQTT v3.1 bridging with TLS encryption |
| Packet Buffering |
Buffering of LoRa frames in Packet Forwarder mode during NS outages (no data loss) |
| Duplex Mode |
Full duplex (optional) |
| Listen Before Talk |
Optional |
| Fine Timestamping |
Optional |
