Description
Overview
Asset Track Pro RFID Animal Tag with Long Range for Livestock Identification can be used in large or medium size livestock or animals, such as pig, cow, lamb, horse, deer, dog and so on. It can be widely applied in all the field of information management for animals and livestock, such as breeding population, epidemic prevention and quarantine control.
Technical Specifications
| Materials | TPU |
| Frequency | 125 kHz to 134.2 kHz or 860 MHz to 960 MHz |
| Operating Temperature | -40°F to 185°F (-40 ᵒC to 85 ᵒC) |
| Printing | Laser or Print ID, Encode |
| Specification | 15.748 in × 9.843 in × 5.512 in (40 cm × 25 cm × 14 cm) |
| Use | Cattle or Sheep or Cow, etc |
| Color | Yellow, Pink or Customized |
| Application | Animal Identification |
| Size | Yellow: Male tag: Diameter 1.181 in (30 mm), thickness: 0.053 in (1.35 mm) Female tag: 2.95 in × 1,8 in × 112 in (72 mm × 45 mm × 2.85 mm) HDX Male tag: Diameter 1.220 in (31 mm), thickness: 0.079 in (2 mm) Female tag: Diameter 1.102 in (28 mm), thickness: thick 0.571 in (14.5 mm), thin 0.242 in (6.15 mm) Pink: Male tag: Diameter 1.259 in (32 mm), thickness: 0.053 in (1.35 mm) Female tag: Diameter 0.827 in (21 mm) , thickness: 0.112 in (2.85 mm) |
| Frequently-Used Chip | LF (125 KHz or 134.2 KHz): EM4200 (Memory size: 128 bits), ATA5577 (Memory size: 363 bits), Hitags256 (Memory size: 256 bits) UHF: (860-960 MHz): Higgs 3 (Memory size: 512 bits) |
| Reading Distance | LF ear tag: 0.394 in to 5.906 in (1 cm to 15 cm) (depend on the size of the tag) UHF ear tag: > 13.12 ft (4 m) |
| Available Craft | Last 8 ID Digit Laser Marked Number. |
| Physical Environment | With tamper proof design and polyurethane material, our ear tag can work in 14 °F to 140 °F (-10 °C to 60 °C), resist +5 KV or – 5 KV peak and it has been worked for 3 to 5 years. |
