| CPU |
Cortex-A7 |
| Main Frequency |
528 MHz |
| Internal Storage |
512 MB |
| Flash Memory |
8 GB |
| Ethernet |
10 or 100M adaptive dual-network port |
| PDA |
BLE 4.2 |
| Communication Mode |
4G Cat.1 |
| Wireless System |
LoRa full duplex |
| LoRa Service Frequency |
Domestic: 470 to 510 MHz, Multi-band options: IN 865 or RU 864 or EU868US915 or AU 915 or KR 920 or A5923 |
| 4G Operating Frequency |
LTE-FDD B1 or 3 or 5 or 8, LTE-TDD B34 or 38 or 39 or 40 or 41 |
| LoRa Receive Channel |
8-way 125 KHz SF adaptive (5 to 12), Channel 1-way 125 or 250 or 500 bandwidth |
| LoRa Transmitting Power |
22 dBm |
| LoRa Reception Sensitivity |
-141 dBm (SF12 & BW125KHz) |
| 4G Communication Protocol |
TCP or UDP or MQTT (software configurable) |
| Data Format |
Transmission or TLV or JSON (software upgradable) |
| 4G Data Rate |
LTE-FDD (Downlink 10 Mbps, Uplink 5 Mbps), LTE-TDD (downlink 8.9 Mbps, uplink 3 Mbps) |
| LoRa Data Rate |
300 bps to 62.5 kbps |
| Service Voltage |
DC 9 to 24 V |
| Protection Level |
IP67 |
| Machine Power |
3 W |
| Work Environment |
Temperature: -40 °F to 158 °F (-40 °C to 70 °C), Relative Humidity: 95% RH (no condensation) |
| Product Size |
9.25 in x 8.38 in x 2.83 in (23.5 x 21.3 x 7.2 cm) |
