| Se |
Aquaculture |
| Mounting Type |
Input, Throw Into The Water |
| Theory |
Polarography |
| Output |
Rs495 Output, Modbus Communication Protocol |
| Voltage Supply |
12 V To 24 V Dc |
| Output Type |
Rs485 Output |
| Measuring Range |
0 Mg/L To 20 Mg/L |
| Resolution |
0.01 Mg/L |
| Voltage Max |
12 V To 24 V Dc |
| Voltage Rated |
12 V To 24 V Dc |
| Voltage Input |
12 V To 24 V Dc |
| Output Function |
Do Value |
| Application |
Aquaculture, Sewage Treatment, River Water Quality Monitoring |
| Wireless Output |
Lora Or Lorawan (Eu868 Mhz, 915 Mhz), Gprs, Nb-Iot |
| Keywords-1 |
4 Ma To 20 Ma Output |
| Keywords-2 |
0 V To 2 V Or 0 V To 5 V Or 0 V To 10 V Output |
| Keywords-3 |
Do Sensor |
| Do Accuracy |
±0.5% Fs |
| Stability |
Less Than 1% During The Life Of The Sensor |
| Housing Material |
Abs |
| The Farthest Lead Length |
Rs485 0.62 Mile (1 Km) |
| Standard Cable Length |
6.56 Ft (2 M) |
| Protection Level |
Ip65 |
| Mounting Brackets |
4.92 Ft, 6.56 Ft (1.5 M, 2 M) The Other Height Can Be Customize |
| Measuring Tank |
Can Be Customize |
| Humidity Range |
0% To 100% |
| Operating Temperature |
32 °F To 140 °F (0 °C To 60 °C) |
| Temperature Resolution |
32.28 °F (0.1 °C) |
| Temperature Accuracy |
±32.54 °F (±0.3 °C) |
| Storage Condition |
-40 °F To 140 °F (-40 °C To 60 °C) |
