| Hardware System |
CPU: Quad-core 1.5 GHz, 64-bit ARM Cortex-A53 |
| Memory |
512 MB DDR4 RAM |
| Flash |
8 GB eMMC |
| LoRaWAN |
Antenna: Fully Integrated Internal (Optional: 2 x 50 Ω N-female external) |
| LoRaWAN Frequency Band |
AU915 or AS923 |
| Sensitivity |
-140 dBm @292bps |
| Output Power |
27dBm Max |
| LoRaWAN Protocol |
V1.0 Class A or Class C, V1.0.2 Class A or Class C |
| Ethernet Interface |
Port: 1 x RJ45 (PoE PD supported), 10 or 100 or 1000 Base-T (IEEE 802.3) |
| Data Rate |
10 or 100 or 1000 Mbps (auto-sensing) |
| Wi-Fi |
Antenna: Fully Integrated Internal, Standards: IEEE 802.11 b or g or n |
| Power Supply |
1 x 802.3 af PoE input, 1 x 12 VDC with M12 Connector |
| Power Consumption |
Typical 3.6 W, Max 4.8 W |
| Ingress Protection |
IP67 |
| Ethernet Isolation |
1.5 kV RMS |
| Relative Humidity |
0% to 95% (non-condensing) at 77 °F (25 °C) |
| Operating Temperature |
-40 ℉ to +158 ℉ (-40 °C to +70 °C) |
| Storage Temperature |
(-40 ℉ to +185 ℉ (-40 °C to +85 °C) |
| Dimension |
9.84 in x 6.77 in x 3.62 in (25 cm x 17.2 cm x 9.2 cm) |
