| Application |
M2M and IoT application |
| Type |
LoRaWAN, BLE module |
| Bluetooth Protocol |
5.0, iBeacon |
| Bluetooth TX Power |
-20 dBm to +4 dBm TX power, configurable in 4 dB steps |
| Bluetooth Sensitivity |
-96 dBm |
| LoRaWAN Protocol |
LoRaWAN 1.0.2B class A |
| LoRa Distance |
>0.62 Mile (>1 km) in urban area |
| LoRa Sensitivity |
137 dBm @ SF12, BW125 kHz, 868 MHz or 915 MHz |
| GNSS Band |
GPS, BDS, GALILEO, GLONASS, QZSS, SBAS (WAAS, EGNOS, GAGAN, MSAS) |
| LoRa Band |
US915, AU915, EU868, EU433, AS923, RU864, KR920, IN865, CN470 |
| Housing Material |
PC and ABS |
| G-Sensor |
Supported |
| Encryption |
AES128 |
| Battery |
Li/SOCl2 4000 mAh × 2 |
| Ingress Protection |
IP67 |
| Adjustable Position Report Interval |
5s x n (1 to 65536) |
| Heartbeat Report Interval |
30s x n (1 to 65536) |
| Switch |
Magnetic reed |
| Removal Detection |
Support |
| FOTA over Bluetooth |
Support |
| GNSS (Report Interval >10 Mins) |
Approx. 30,000 times |
| Bluetooth Positioning |
Approx. 500,000 times |
| Operating Temperature |
-40 °F to 185 °F (-40 °C to 85 °C) |
| Dimension |
1.02 in × 1.22 in × 8.07 in (2.6 cm × 3.1 cm × 20.5 cm) (6.88 in (17.5 cm), without the mounting lug) |
| Weight |
4.58 oz (130 g) |
