| Bluetooth Protocol |
Bluetooth 5.0, iBeacon |
| Bluetooth TX Power |
-20 dBm to + 4 dBm, configurable in 4dB steps |
| Bluetooth Sensitivity |
-96 dBm |
| Bluetooth Accuracy |
9.8 ft (3 m) |
| LoRaWAN Protocol |
LoRaWAN 1.0.2B, Class A |
| Activation Mode |
OTAA or ABP |
| LoRaWAN Bands |
US 915, AU 915, EU 868, EU 433, AS 920 to 923, AS 923 to 925, RU 864, ID 920, KR 920, IN 865, KZ 865, CLAA, CN 470, CN470-Ali |
| LoRa TX Power |
0 dBm to 20 dBm |
| LoRaWAN Range |
>0.62 mi (1 km) in urban areas |
| Encryption |
AES128 |
| GNSS Band |
1575 MHz to 1610 MHz |
| GNSS Tracking Accuracy |
8.2 ft (2.5 m) |
| GNSS Cold Start |
30 s to 60 s |
| Battery Capacity |
Li-ion, 1000 mAh |
| GNSS Reports (Report Interval > 10 min) |
Approx. 5,000 times per charge |
| Bluetooth Reports |
Approx. 160,000 times per charge |
| Housing Material |
PC (Polycarbonate) |
| Ingress Protection |
IP66 (Dustproof & Water Resistant) |
| Impact Protection |
IK10 (High Impact Resistance) |
| Standby Current |
25 μA |
| Barometer |
3.9 in (10 cm) altitude accuracy |
| PCB Coating |
Waterproof coating |
| NFC Tag |
1 KB |
| Position Report Interval |
Adjustable 5 s × n (1 to 65536) |
| Heartbeat Report Interval |
Adjustable 30 s × n (1 to 65536) |
| Operating Temperature |
14 °F to 140 °F (-10 °C to 60 °C) |
| Charging Temperature |
32 °F to 122 °F (0 °C to 50 °C) |
| Weight |
3.17 oz (90 g) |
| Device Dimensions |
3.15 in × 3.15 in × 1.38 in (80 mm × 80 mm × 35 mm) |
