Description
Features
- C-Type interface
- High-definition display screen
- Low energy consumption
- Powerful compatibility
- Support LoRaWAN class A, class C protocols
Technical Specifications
| LoRa Baseband Chip | ESP32 |
| LoRa RF Chip | SX1276 |
| Working Band (Optional) | EU 433 MHz, CN 470 MHz to 510 MHz, US 902 MHz to 928 MHz |
| LoRa Maximum Output Power | 18 dB ± 1 dB |
| Interface | USB type-c x 1 |
| USB to Serial Hip | CP2102 |
| Power Supply | USB power supply (≥ 500 mA), 4.8 V min, 5 V typical, 6 V max |
| Power Consumption | 2 channels listening (receive mode) LoRa 10 dB output LoRa 12 dB output LoRa 15 dB output LoRa 20 dB output |
| Demodulator | LoRa demodulator |
| Spectrum Factor | SF 7 to SF 12 for each channel is optional |
| Operating Temperature | -40 °F to 176 °F (- 40 °C to 80 °C) |
| Size | 2.95 in x 1.18 in x 0.51 in (75 mm x 30 mm x 13 mm) |
