| PH |
0 ph to 14 ph Range; 0.01 ph rRsolution; ± 0.1 ph Accuracy |
| DO |
0 mg per L to 20 mg per L Range; 0.01 mg per L resolution; ± 0.6 mg per L Accuracy |
| Turbidity |
0 NTU to 200 NTU or 0 NTU to 1000 NTU range; 0.1 NTU resolution; < 3 % F.S. accuracy |
| EC |
0 uS per cm to 500 uS per cm or 0 mS per cm to 200 mS per cm or 0 PSU to 70 PSU range; 1 uS per cm or 0.1 mS per cm or 0.1 PSU Resolution; ± 1.5 % F.S. Accuracy |
| Temperature |
32 °F to 140 °F (0 °C to 60 °C) range; 32.18 °F (0.1 °C) resolution; ± 32.9 °F (0.5 °C) accuracy |
| Output |
RS485, MODBUS Communication Protocol |
| Electrode Type |
Multi Electrode with Protect Cover |
| Wide V0ltage Input |
12 V DC |
| Standard Cable Length |
6.56 ft (2 m) |
| Farthest Lead Length |
RS 485 3280.84 ft (1000 m) |
| Wireless Transmission |
LoRa or LoRaWAN (EU 868 MHz, 915 MHz), GPRS, 4 G, Wi-Fi |
| Protection Level |
IP68 |
| Protection Isolation |
Up to Four Isolations, Power Isolation, Protection Grade 3000 V |
| Working Humidity |
0 % RH to 100 % RH |
| Working Temperature |
32 °F to 140 °F (0 °C to 60 °C) |
| Device Dimensions |
15.7 in × 3.9 in (400 mm x 100 mm) |
