| Chipset |
SX1302 |
| Application |
LoRaWAN |
| Type |
LoRa Module |
| Supplier Type |
Manufacturer |
| Color |
White |
| Working Frequency |
433/470/868/915 Multi-band Optional |
| Communication Rate |
250bps to 5.4 KBPS (@125 kHz) |
| Transmitting Power |
+27dBm Max (antenna port +26dBm Max) |
| Reception Sensitivity |
SF10 ≤ 136dBm |
| Antenna Gain |
-5dBi Glue Stick Antenna (optional) |
| Business Channel |
8 Channel Uplink, 1 Channel Downlink |
| Working Mode |
Half Duplex, Same Frequency/Different Frequency |
| USB |
4-way Interface |
| Data |
Return Ethernet |
| Debugging Interface |
Wi-Fi Hot Spot Nearby Management |
| Power Supply Parameter |
9V to 36V DC |
| Power Supply Mode |
Supports DC Power Supply and POE Power Supply |
| Complete Machine Power Consumption |
3.6 W (Typical Value) |
| Relative Humidity |
5% to 95%, No Frost |
| Working Temperature |
-13°F to 158°F (-25℃ to 70℃) |
| Storage Temperature |
-40°F to 185°F (-40℃ to 85℃) |
