| Type |
Remote Control |
| Max Load Power |
500 W |
| Connection Mode |
OTAA |
| Material |
Plastic |
| Function |
Street light controller with LoRa communication |
| Usage |
Lighting |
| Certificates |
CE, FCC, CB |
| EMC |
EN55015, EN55022 |
| Range |
1.24 mile to 3.1 mile (2 km to 5 km) |
| Dimming Type |
0 V to 10 V/PWM/DALI |
| Output |
Single |
| Main IC |
SX1276 RP2040 |
| LoRaWAN Frequency |
EU433, CN470, EU868, US915, AS923, AU915, KR920, IN865 |
| Input Voltage |
100 V AC to 480 V AC |
| Rated Voltage |
480 V AC |
| Input Frequency |
47 Hz to 63 Hz |
| Max Current |
4 A |
| Standby Power |
<2 W |
| Dimming Output |
0 V to 10 V @ 27 mA (max) |
| Measurement Accuracy |
<1.5% |
| Harmonic Content |
<10% |
| Overload Protection |
Yes |
| Short Circuit Protection |
No |
| Overheating Protection |
Yes |
| MTBF |
>200 khours |
| Waterproof |
IP66 |
| Operating Temperature |
-40 °F to 140 °F (-40 °C to 60 °C) |
| Storage Temperature |
-40 °F to 185 °F (-40 °C to 85 °C) |
| Case Max. Temperature |
176 °F (80 °C) |
| Size Packaging |
3.54 in × 3.54 in × 4.52 in (9 cm × 9 cm × 11.5 cm) |
| Weight |
0.66 lb (0.3 kg) |
