Description
Features
- Compatible with worldwide LoRaWAN® networks; supports universal frequency plan from 863 MHz to 928 MHz.
- Ultra-wide transmission range: 2 km in urban areas, 10 km line-of-sight; powered by replaceable Li-SOCl2 battery (ER34615) with up to 10 years battery life.
- Designed for harsh environments: operates at -40 to 185 °F (-40 to 85 °C) with IP66-rated enclosure, resistant to UV, heavy rain, and dust.
- Simple configuration: no-code setup via SenseCAP Mate APP in 4 easy steps.
Technical Specifications
| Type | Development Board |
| Core Processor | Wio-E5 |
| Operating System | LoRaWAN v1.0.3 Class A |
| Function | Soil Moisture, Temperature, and EC Sensor |
| Sampling Rate | 0 to 50%: ±3%, 50 to 100%: ±5% |
| Voltage – Supply | Standard D-size SOCl2 Battery |
| Current – Output | 19 Ah (non-rechargeable) |
| Frequency – Switching | IN865, EU868, US915, AU915, AS923, KR920, RU864 |
| Sensitivity | -136 dBm @ SF12 BW=125 kHz |
| Sensing Range | 1.24 to 6.21 mi (2 to 10 km, depending on gateway antenna and environment) |
