| Measuring Medium |
Water, gas, oil |
| Measurement Range |
– 100 kPa to 60 MPa |
| Power Supply Voltage |
3.6 V battery power supply DC 12 V to 30 V external power supply |
| Accuracy |
± 0.5 % FS ± 1 % FS |
| Long-Term Stability (1 Year) |
≤ 0.2 % FS |
| Overload Pressure |
200 % FS |
| Working Frequency Band |
470 MHz or 868 MHz |
| Sampling Frequency |
10 s to 12 h can be set (default 10 s) |
| Sending Frequency |
1 min to 1440 min can be set (default 2 min) |
| Communication Protocol |
Private Protocol or LoRaWAN (Class A, OTAA Mode Activation) |
| Protection Grade |
IP65 |
| Housing Material |
Aluminium die casting, 304 stainless steels |
| Pressure Interface |
M20 x 1.5, G1 or G4 or other threads |
| Power Consumption Current |
Sleep current: < 5 uA, sampling current: < 5 mA, transmit current: < 140 mA, receiving current: < 20 mA |
| Battery Capacity |
8000 mAh |
| Display Mode |
6-segment LCD display |
| Storage Environment |
– 104 °F to 176 °F (- 40 °C to 80 °C); Humidity: 0 % to 95 % RH |
| Temperature Compensation |
– 14 °F to 158 °F (- 10 °C to 70 °C) |
| Working Temperature |
Temperature: – 4 °F to 140 °F (- 20 °C to 60 °C) |
