| Frequency |
865 MHz to 868 MHz (EU) or 902 MHz to 928 MHz (US) |
| Protocol |
ISO18000-6C (EPC GEN2) |
| Work Mode |
FHSS |
| RF Power |
0 dBm to 30 dBm (adjustable) |
| Read Mode |
Auto mode or Command mode or Trigger Mode |
| Read Speed |
Set by software, 64bits per less than 6ms |
| Interface |
RS 232, RS 485, RJ 45, Wiegand 26 or 34, Trigger, Relay |
| Optional Interface |
WIFI, POE,4G |
| Read Tips |
Buzzer |
| Antenna |
Built-in 7 dBi antenna (Circular Polarization Antenna) |
| Power Supply |
DC -12 V (with power adapter), voltage range from 9 V to 16 V |
| Read Distance |
0 ft to 16.4 ft (0 m to 5 m) (depends on tags) |
| Operating Temp |
-4 °F to 176 °F (-20 ℃ to +80 ℃) |
| Reader Size |
9.25 in x 9.25 in x 2.28 in (235 mm x 235 mm x 58 mm) |
| Net Weight |
2.20 lb (1 kg) |
