Description
Features
- Works on 4G CAT1 + 2G GSM networks
- Precise accuracy positioning
- GPS+BDS+LBS location modes
- Super long standby time
- Powerful magnet, free installation
- Waterproof IP65
- Tracked by SMS, mobile APP, web platform
Technical Specifications
| Parameters | Description |
| Work Voltage | DC 3.4 V to 4.5 V |
| Work Current | 4 V, Average 355 mA |
| Sleep Current | 4 V, Average 60 µA |
| Internal Battery Capacity | 5000 mAh (3.7 V Polymer battery) |
| Work Humidity | 10 % to 85 % Non-condensing |
| 4G LTE Module | SIMCOM 7670SA |
| Frequency Bands (SIMCOM 7670SA) | LTE-FDD: B2, B3, B4, B5, B7, B8, B28, B66 GSM: B3, B5, B8 |
| Frequency Bands (SIMCOM 7670E) | LTE-FDD: B3, B5, B7, B8, B20 GSM: B8 |
| GPS Chipset | ZKMicro AT6558D |
| Sensitivity (Tracking) | -162 DBM |
| Frequency | GPS: L1: 1575.42 ±1.023 MHz BD: B1: 1561.098 ±2.046 MHz |
| TTFF (Open Sky) | Cold Start: Average 32 s; Hot Start: Average 1 s |
| Suitable for | SIMCOM 7670SA: North and South America; SIMCOM 7670E: EU, Southeast Asia, Africa regions |
| Work Temperature | -4 °F to 167 °F (-20 °C to 75 °C) |
| Dimension | 3.07 in x 2.09 in x 0.83 in (7.8 cm × 5.3 cm × 2.1 cm) |
| Weight | 1.13 oz (32 g) |
