| Fiber Type |
SM |
| Connector Type |
SC/FC/ST |
| Wavelengths |
1310 nm/1550 nm |
| Dynamic Range |
24/22 dB |
| VFL Output power |
≥10mW |
| Certification |
CE RoHS FCC |
| Language |
Multi-language |
| OED/ODM |
Support |
| Red Light Source |
10 mW, CW/2Hz |
| Data Interface |
2 USB ports (type A x 1, Micro USB x 1), SD card |
| Monitor |
4.3 in TFT-LCD (standard capacitive touch screen) |
| Battery |
3.7 V/5200 mAh |
| Optical Power Meter |
Type A: -10 dBm to –70 dBm, Type B: +26 dBm to –50 dBm |
| Network Cable Test Terminal |
Support network cable sequence test |
| Distance Range |
Up 62 mi (Up 100 km) |
| Sampling Resolution |
0.65 ft minimum (0.2 m minimum) |
| Sampling Point |
64,000 points |
| Linearity |
=0.05 dB/dB |
| Loss Threshold |
0.01 dB |
| Loss Resolution |
0.001 dB |
| Range Resolution |
0.03 ft (0.01 m) |
| Distance Accuracy |
+(1.64 ft + test distance x 3 x 10^-5+sampling resolution) (excluding refractive index error) |
| Humidity |
=95 % (no condensation) |
| Working Temperature |
14 °F to 131 °F (-10 °C to 55 °C) |
| Storage Temperature |
-4 °F to 176 °F (-20 °C to 80 °C) |
| Dimension |
6.9 in x 4.1 in x 1.8 in (17.5 cm x 10.5 cm x 4.5 cm) |
| Weight |
1.2 lb. (including battery) (0.56 kg (including battery)) |
