Description
Technical Specifications
| Protocol | Modbus RTU or Modbus TCP |
| Communication Frequency | 433 MHz to 868 MHz |
| Transmission mode | 2G or 3G or 4G or RJ45 |
| Input Voltage | 9 to 36 V DC |
| Protection level | IP30 |
| Network protocol | IPV4,TCP OR UDP,DHCP,DNS, Modbus RTU, Modbus TCP, MQTT |
| Power supply protection | Anti-reverse, ESD air:15 KV, surge:4 KV |
| Interface | 1 x RJ45, 10 or 100 Mbps |
| Battery backup | 3.7 V or 900 mAh |
| Power consumption | Normal:130 mA @ 12 V, Max:150 mA @ 12 V |
| Power Supply | Input Voltage: 9 V DC to 36 V DC Power Consumption: Normal: 130mA@12V, Max: 150mA@12V |
| Protection | Anti-reverse, ESD Air: 15KV, Surge: 4KV ESD Contact: 8KV, Surge: 4KV (10 or 1000µs) |
| Backup Battery | 3.7V / 900mAh |
| Interfaces | 1 x Mini USB 1 x RJ45 Ethernet, 10/100Mbps |
| Communication Protocols | Modbus RTU, Modbus TCP, MQTT, IPv4, TCP/UDP, DHCP, DNS |
| Frequency Band | 402 MHz to 500 MHz |
| Protection Level | IP30 |
| Installation Method | Wall-mounted, Rail-mounted |
| Working Temperature | 14 °F to 158 °F (-10 °C to 70 °C) |
| Size | 3.35 in x 2.95 in x 1.18 in (8.5 cm x 7.5 cm x 3.0 cm) |
| Weight | 8.28 oz (235 g) |
