| Wavelength |
1310/1550 nm |
| Dynamic Range |
38/37 dB |
| Display |
7-inch TFT Touch Screen (800×480) |
| Emitter Type |
LD |
| Connector |
FC/PC (Interchangeable SC, ST, LC) |
| Use |
FTTH |
| Display (Alternate) |
8-inch TFT Touch Screen (800×480) |
| Connectivity |
USB×2; 10/100Mbit/s RJ-45×1 |
| Memory |
8 GB |
| Power Supply |
Rechargeable Li-Ion Battery/AC Adapter |
| Battery Life |
6 hours continuous operation |
| Selectable Range (SM) |
0.808 mi (1.3 km), 1.553 mi (2.5 km), 3.107mi (5 km), 6.214mi (10 km), 12.427mi (20 km), 24.855 mi (40 km), 49.709 mi (80 km), 99.419 mi (160 km), 149.129 mi (240 km) |
| Selectable Range (MM) |
0.808 mi (1.3 km), 1.553 mi (2.5 km), 3.107 mi (5 km), 6.214 mi (10 km), 12.427 mi (20 km), 24.855 mi (40 km) |
| Humidity |
0 % to 95% (non-condensing) |
| Storage Temp |
-40 °F to 158 °F (-40 °C to +70 °C) |
| Working Temp |
-4 °F to 122 °F (-20 °C to +50 °C) |
| Dimensions (L×W×H) |
9.25 in × 6.26 in × 2.95 in (23.5 cm × 15.9 cm × 7.5 cm) |
| Weight |
3.31 lb (1.5 kg) |
