| Network |
FDD-LTE or TDD-LTE, multi-region, backward compatible with 3G or 2G |
| Ethernet |
1 x LAN (100 Mbps), 1 x WAN or LAN (100 Mbps) |
| WI FI |
2.4 GHz |
| Serial Port |
1 x RS232, 3 x RS485 |
| Input/Output |
12 x AI, 12 x DI Dry Contact, 4 x DI Wet Contact |
| GNSS (Optional) |
GPS or GLONASS or BeiDou or Compass or Galileo or QZSS |
| Antenna Interface |
1 x SMA (3G or 4G), 1 x WIFI 2.4G, 1 x GPS, 1 x Aux |
| USB |
1 x USB 2.0 |
| SIM |
1 x SIM or UIM slot, 1.8 V or 3 V auto-detection |
| Power |
9 V to 32 V (Default: DC 12 V or 1.5 A) |
| Humidity |
<95% (No Condensation) |
| Temperature Range |
-22 °F to 167 °F (-30 °C to 75 °C) |
| Dimension |
9.29 in x 4.92 in x 1.57 in (26.3 x 12.5 x 4 cm) |
| Weight |
1.10 lb (500 g) |
