| LCD |
Color LCD, Multi-touch screen, 7 inches |
| Connector |
FC/PC (850 to 1550nm), FC/APC (1625nm), interchangeable or customizable |
| Min. Distance Resolution |
(0.1 m) 3.94 in |
| Loss Resolution (dB) |
0.001 |
| Max Sampling Point |
25600 |
| Distance Uncertainty |
± (2.62ft + 0.005% × Testing Distance + Resolution) |
| OPM Function |
+26 dBm to –50 dBm, 850 nm to 1650 nm, FC or SC adapter |
| VFL Function |
10 mW |
| Loss Test |
Yes |
| Storage |
>10000 results |
| Battery |
7.4V/4.6AH Rechargeable lithium-ion batteries |
| Network |
Wireless LAN, Wi-Fi, 4G |
| Connector Type |
SC, FC, ST connector |
| Fiber Type |
Single mode/Multimode |
| Display |
Color LCD, Multi-touch screen, 7 in |
| Wavelength |
1310/1550 nm, 850/1300 nm, or up to 5 wavelengths in one device |
| VFL |
10mW |
| OPM |
Real-time monitoring |
| OLS |
Same wavelength as OTDR |
| Size |
12.99 in × 9.06 in × 11.02 in (33 cm × 23 cm × 28 cm) |
