| Interface |
USB(principal and subordinate each), RJ45 |
| LCD |
4.3 Inch, 16:9 480 x 272 Dot-Matrix TFT Touch Screen |
| Power |
AC/DC Adapter (Input AC 90-240 V±10%, Output 12 V) |
| Battery |
Rechargeable Li-Ion Battery Inside (charging Time< 4hours, working Time> 8hours) |
| Distance Accuracy |
± 1.64 ft (0.5 m) +0.0001% × Distance Sampling Resolution |
| Distance |
16.40 ft to 124 mi (5 m to 200 km) |
| Pulse Width |
5 μs to 20 μs |
| Measurement Time |
User Defined |
| Attenuation Accuracy |
0.005 dB |
| Loss Threshold |
0.001 dB |
| Loss Resolution |
0.001 dB |
| Distance Resolution |
0.09 ft (0.03 m) |
| Sampling Quantity |
128000 |
| Linearity |
0.05 dB/dB(AE2300) 0.03 dB/dB(AE2300H) |
| Data Storage |
3000 pcs |
| VFL |
10 mW AE2300(option), AE2300H(standard) |
| Fiber Adapter |
FC/PC, SC/PC |
| Relative Humidity (RH) |
<80% |
| Working Temperature |
32 ℉ to 104 ℉ (0 ℃ to 40 ℃) |
| Storage Temperature |
-4 ℉ to 158 ℉ (-20 ℃ to 70 ℃) |
| Dimension(L*W*H) |
5.31 in x 9.84 in x 2.75 in (13.5 cm x 25 cm x 7 cm) |
| Weight |
< 2.20 lb (1kg) |
