| Connector Type |
FC/φ 0.98 in (0.25 cm) universal 0.049 In (0.125 cm) universal, Bare fiber adaptor, support HP8100BA adaptor; |
| Wavelength |
1310/1550 nm or 850/1300 nm |
| Measurement Range |
0 dB to 75 dB |
| Calibration Wavelength |
1310/1550 nm or 850/1300 nm |
| Measurement Accuracy |
1 dB |
| Wavelength |
1310/1550 nm or 850/1300 nm |
| Output Power |
≥-3 dBm |
| Output Stability |
±0.005 dB (one hour @ 77 ℉ (25℃) |
| Connector Type |
FC/APC |
| Wavelength |
1310/1550 nm or 850/1300 nm |
| Measurement Range |
0 dBm to -40 dBm |
| Linearity |
±0.03 dB |
| Displaying Resolution |
Log：0.01 dB；Linear：0.001 nw/µW/mW |
| Wavelength |
650 nm |
| Central Wavelength |
650 nm ±20 nm |
| Output Power（dBm） |
0(10 dBm for optional) |
| Communication Port |
USB |
| Power Supply |
AC 170 V to 260 V AC 50 Hz |
| Operation Temperature |
14 ℉ to 140 ℉ (-10 ℃ to +40 ℃) |
| Packing Size |
19/82 in x 12.20 in x 6.69 in (27.5 cm x 31 cm x 17 cm) |
| Weight |
12.78 lb. (5.8 kg) |
