| Type |
OTDR |
| Network |
Wireless LAN, SDK, TCP/IP, POE, GPRS, Wi-Fi, GSM, 3G |
| Event Blind Zone |
6.6 ft (2 m) |
| ATT Blind Zone |
39.4 ft (12 m) |
| Dynamic Range |
22 to 20 dB |
| Display |
High-resolution touchscreen |
| Storage Capacity |
4 GB internal, expandable with USB |
| Power Supply |
Rechargeable lithium battery |
| Battery Life |
8 to 10 hours continuous operation |
| Charging Time |
2 to 3 hours |
| Supported Languages |
English, Spanish, Portuguese, French, Chinese, etc. |
| Type of Connectors |
FC/PC, SC/PC (Optional: FC/APC, SC/APC) |
| VFL Output Power |
1 mW |
| OPM Range |
-50 to +26 dBm |
| Certifications |
CE, RoHS, FCC |
| Humidity |
0% to 95% non-condensing |
| Laser Safety |
Class 1 laser product |
| Weight |
3.3 lbs (1.5 kg) |
| Dimensions |
17.7 x 11.8 x 7.9 inches (45 x 30 x 20 cm) |
| Operating Temperature |
14°F to 122°F (-10°C to 50°C) |
| Storage Temperature |
-4°F to 140°F (-20°C to 60°C) |
