| Wavelengths |
1310nm±20nm / 1550nm±20nm |
| Maximum Dynamic Range |
28/26dB |
| Event Dead Zone |
4.9 ft (1.5m) |
| Attenuation Dead Zone |
19.7 ft (6m) |
| Test Range |
Up to 62.1 miles (100km) |
| Ranging Accuracy |
±(2.5 ft (0.75m) + sampling interval + 0.005% × test distance) |
| Linearity |
±0.05dB/dB |
| Maximum Sampling Resolution |
≤0.1 ft (0.03m) |
| Reflection Accuracy |
±3dB |
| File Format |
SOR standard file format |
| Loss Measurement Mode |
4-point method / 5-point method |
| Optical Connectors |
FC/SC Interchangeable, universal interface |
| Optical Power Meter Range |
800 to 1700nm |
| Optical Power Meter Measuring Range |
-70 to +6dBm (optional) / -50 to +26dBm (standard) |
| Visual Fault Locator Operating Wavelength |
650nm ± 20nm |
| Display |
Full touch 5-inch, 800 x 480 color LCD |
| Working Hours |
Standby > 12h, continuous test >8h |
| Data Interface |
Type-C USB |
| Relative Humidity |
0 to 95% Non condensation |
| Operating Temperature |
14 °F to 122 °F (-10 °C to 50 °C) |
| Storage Temperature |
-40 °F to 158 °F (-40 °C to 70 °C) |
| Dimension |
6.7 in x 6 in x 2.3 in (17 cm x 15.4 cm x 5.8 cm) |
| Total Weight |
≤ 24,69 oz (700g) with battery |
