| Network |
Wireless LAN, WiFi, 4G, 3G |
| Connector Type |
SC/FC/ST |
| Fiber Type |
Single Mode |
| Wavelength |
1310/1550 nm |
| Dynamic Range |
24/22 dB |
| VFL Output Power |
10 mW |
| Optical Power Meter Module |
-50 dBm to +26 dBm |
| Optical Light Source Module |
1310/1550 nm |
| Testing Data Storage |
600 |
| Battery Capacity |
4000 mAh |
| Event Blind Zone |
9.84 ft (3m) |
| ATT Blind Zone |
26.25 ft (8 m) |
| Test Range |
0.31 mi to 37.28 mi (0.50 km to 60 km) |
| Pulse Width |
3 ns to 10 us |
| Ranging Accuracy |
± 3.28 ft (1m + Sampling interval + 0.005% × Test distance) |
| Loss Accuracy |
±0.05 dB/dB |
| Sampling Points |
16 k to 128 k |
| Sampling Resolution |
0.164 ft to 26.25 ft (0.05 m to 8 m) |
| Reflection Accuracy |
±3 dB |
| Data Storage |
Internal: ≥600; External: TF Card |
| Laser Safety Level |
Class II |
| File Format |
SOR Standard file format |
| Connector |
FC/UPC (Interchangeable SC, ST) |
| Wave Range |
800nm to 1700nm |
| Interface Type |
Universal Joint FC/SC/ST |
| Test Range (Optical Power Meter) |
-50 dBm to +26 dBm |
| Uncertainty |
±5% |
| Frequency Identification |
CW/270/330/1k/2kHz |
| Calibration Wavelength |
850/980/1300/1310/1490/1550/1625/1650nm |
| Output Power (Optical Power Meter) |
≥-5 dBm |
| Modulation Frequency |
270/330/1k/2kHz |
| Stability |
CW, ±0.5dB/15min (Test after 15 minutes of preheating) |
| Connector (VFL) |
FC/UPC (Interchangeable SC, ST) |
| Wavelength (VFL) |
650 nm ± 20 nm |
| Output Power (VFL) |
≥10 mW |
| Mode (VFL) |
CW/1Hz/2Hz |
| Test Range (VFL) |
984.25 ft (300 m) |
| Display |
3.5 in Color LCD |
| Data Interface |
Micro USB |
| External Storage |
TF Card |
| Power Supply |
Polymer Li-Battery: 3.7V, 4000mAh; Adapter: 5VDC, 2A |
| Battery Life |
Standby > 20h; Measuring Time > 12h |
| Relative Humidity |
0 % to 95 % non-condensing |
| Operating Temperature |
14°F to 122°F (-10℃ to +50℃) |
| Storage Temperature |
-40°F to 158°F (-40℃ to +70℃) |
| Dimensions |
6.81 in × 3.23 in × 1.46 in (17.3 cm × 8.2 cm × 3.7 cm) |
| Size |
6.81 in × 3.23 in × 1.46 in (17.3 cm × 8.2 cm × 3.7 cm) |
| Weight |
≤12.35 oz (350 g) |
