| Meter Type |
Appliance meter |
| Test Voltage |
500 V/1000 V |
| Insulation Resistance Measuring Ranges |
0,5 M to 200 MΩ |
| Loop Impedance Measurement |
0,4Ω to 20Ω/2000Ω (rated test current 25 A (20Ω) 15 mA (2000Ω);, measuring time 10 ms (20Ω) 350 ms (2000Ω) |
| AC Voltage Measuring Range |
100 V to 300V |
| Touch Voltage Measurement |
0 to 100 V |
| Sealing |
IP40 |
| Continuity Test |
0,2Ω to 20Ω/200Ω |
| Display |
LCD 3,5 digit (1999) |
| Power Supply |
8 batteries 1,5 V LR06 (AA) |
| Safety |
EN61010: CAT III 300 V |
| AC Voltage Measuring Accuracy |
3% |
| Loop Impedance Measuring Accuracy |
± (3% + 8 digits) |
| Power Supply |
8 batteries 1,5 V LR06 (AA) |
| RCD Parameters Measurement |
IDN rated current settings: 32.80 ft/98.42 ft/328 ft/ 1.94 ft (10 m/30 m/100 m/300 m/500 m) |
| Bandwidth for AC Voltage Measurements |
50 Hz |
| Weight with Battery |
29.63 oz (840 g) |
