| Use |
FTTH |
| Network |
Wireless LAN, 4G, Bluetooth, POE, Wired LAN, GPRS, ONVIF, Wiegand |
| Usage |
Fiber optic diagnostics and on-off detection |
| Function |
Multifunctional touchscreen |
| Feature |
Touchscreen |
| Advantage |
High working efficiency |
| Application |
Fiber optic line inspection |
| Used for |
Fiber optic signal transmission processing |
| Dynamic Range |
26/24 dB |
| Testing Range |
0.193.2 mi (0.1150 km) |
| Wavelength |
1310±20 nm, 1550±20 nm |
| OTDR/OLS Interface |
FC/UPC (Selectable SC/UPC; FC/APC; SC/APC) |
| Pulse Width |
5 ns to 20 µs |
| Event Dead Zone |
6.56 ft (2 m) |
| Attenuation Blind Zone |
26.25 ft (8 m) |
| Distance Accuracy |
±1.5% |
| OPM |
-50 dBm to 26 dBm, 2.5 mm Universal Interface @ 850/980/1270/1300/1310/1490/1550/1577/1625/1650 nm |
| VFL |
10 mW |
| Battery |
7.3 V / 5000 mAh Lithium Battery |
| Battery Life |
Standby > 9 hours, measurement > 5 hours |
| Power Supply |
Supports a maximum of 5 V/2 A |
| Operating Temperature |
32°F to 122°F (0°C to 50°C) |
| Storage Temperature |
-22°F to 158°F (-30°C to 70°C) |
| Size |
7.48 in x 3.94 in x 1.77 in (19 cm x 10 cm x 4.5 cm) |
| Weight |
17.64 oz (500 g) |
