| Usage |
Industrial, Benchtop pH Meter, Multiparameter pH Meter |
| Type |
Automatic |
| Customized Support |
OEM, ODM, OBM |
| Accuracy |
DO: ±0.2 mg/L, pH: ±0.1 pH, ORP: ±5mV, Salinity: ±1% F.S., EC: ±1% F.S. |
| Power Consumption |
Max 15 W |
| Output |
Digital output (for integration with IoT) |
| Main Material |
POM Polycarbonate |
| Protection Class |
Display Terminal: IP65; Sensor: IP68 |
| Digital Fluorescent DO Sensor |
Measurement Range: DO: 0mg/L to 20 mg/L, Accuracy: ±0.2 mg/L |
| Digital pH/ORP Sensor |
pH: 0–14, -2000mV to +2000 mV, Accuracy: ±0.1 pH / ±5 mV |
| Digital Salinity (Conductivity) Sensor |
Measurement Range: 0 ppt to 70 ppt, 0 mS/c to 200 mS/cm, Accuracy: ±1% F.S. |
| Sensor Supply Voltage |
12V DC, Max Current: 50 mA |
| Humidity |
95% (non-condensing) |
| Operating Temperature |
-4°F to 185°F (-20°C to 85°C) |
| Storage Temperature |
-4°F to 113°F (-20°C to 45°C) |
| Size |
4 in (10.16 cm) |
