Description
Features
- AR2200s include built-in firewalls; provide IPS and URL filtering; 802.1x, MAC, and portal authentication; and support IPSec VPN, EVPN, DSVPN, and Smart VPN secure access
- Crisp, clear voice communications are assured by built-in PBX, SIP server, and SIP gateway functions; interfaces are provided for connection to third-party NGN/IMS/PBX terminals
- Switching Router Units (SRUs) on AR2240 main control boards are configurable and upgradable for added flexibility
- Millisecond fault detection and link backup ensure high availability; line cards are hot-swappable without disrupting service
- Provides multiple 3G/LTE modes; supports high-speed wireless ACs and multiple APs; integrated wired and wireless access
Technical Specifications
| Network | Wi-Fi, 4G, 3G |
| WAN Speed with Services | 1 Gbit or s |
| Fixed WAN Ports | 4 x GE + 4 x GE SFP +2 x GE Combo |
| SIC Slots | 4 |
| WSIC Slots (default or max.) | 2 or 4 |
| XSIC Slots (default or max.) | 2 or 4 |
| Memory | 2 GB |
| Flash (default or max.) | 2 GB or 8 GB |
| Power Supply | AC 100V to 240V, 50 Hz or 60 Hz |
| Slot | 4 x SIC + 2 x WSIC + 2 x XSIC |
| WAN Speed with Services | 1 Mbit or s |
| Fixed Ports | 4 x GE + 4 x GE SFP + 2 x GE Combo |
| Slots | 4 x SIC + 2 x WSIC + 2 x XSIC |
| WSIC Slots(default/max.) | 0 or 2 |
| Power Supply | AC: 100V to 240V, 50 Hz or 60 Hz |
| Dimensions (H x W x D) | 3.47 in x 17.40 in x 18.50 in (8.81 cm x 44.2 cm x 47 cm) |
