| LAN Ports |
4 |
| Wi-Fi Transmission Standard |
802.11ac |
| Wired Transfer Rate |
10 Mbps or 100 Mbps or 1000 Mbps |
| FLASH |
16 MB Nand Supports 8Gbits |
| WAN Ports |
1 |
| 5G Wi-Fi Transmission Rate |
1733 Mbps |
| Chipset |
MTK7621 |
| RAM |
DDR3: 2 GBites, Max. Is 4Gbits |
| Power Supply |
DC 9 to 24V |
| Wireless Speed |
2.4G: 573 Mbps, 5.8G: 1201 Mbps |
| Function |
Firewall, VPN |
| Max. LAN Data Rate |
1900 Mbps |
| Wi-Fi Supported Frequency |
2.4G |
| 2.4G Wi-Fi Transmission Rate |
600 Mbps |
| Standards And Protocols |
Wi-Fi 802.11b, Wi-Fi 802.11g, Wi-Fi 802.11n, Wi-Fi 802.11ac, Wi-Fi 6 AX1800 |
| Encryption Type |
WPA2-PSK, WPA2, WPA3, WPA2-Enterprise, WPA-PSK, WPA, WEP |
| Protocol |
IEEE802.11N or G or B or AC or AX |
| Working Frequency |
2.4Ghz+MINI PCI-E wireless network card modem |
| Wireless Rate |
2.4G:573 Mbps + 5.8G: 1201 Mbps |
| Wireless Power |
27dBm |
| Power Consumption |
<25W |
| Input Voltage |
9V to 15V |
| Interfaces |
1WAN, 4LAN,1 x RS485,1 x 2.0USB,1 x TF,1 x SIM,1 x RESET,1 x DC24V Input (4P In-vehicle locked terminal) |
| USB |
1 USB 2.0 |
| Frequency |
Dual-band 2.4 GHz or 5.8 GHz |
| Storage Humidity |
5% to 90%RH non-condensing |
| Working Temperature |
-40 ⁰F to 167 ⁰F (-40 °C to 75 °C) |
| Storage Temperature |
-40 ⁰F to 212 °F (-40 °C to 100 °C) |
| Dimensions |
9.88 in x 4.88 in x 1.50 in (25.1 cm x 12.4 cm x 3.8 cm) |
