Description
Features
- Widely operating wavelength range
- Low insertion loss
- High channel isolation
- High stability and reliability
- Ultra flat wide pass band
- Epoxy free optical path
Technical Specifications
| Applicable Fiber | 1310/155 nm CWDM |
| 18 Channel Insertion Loss | < 0.6 db |
| 18 Channel Wavelength Range | 1270 nm to 1610 nm (±6.5 nm) |
| Reflect Channel Wavelength | 1310 nm ± 40 nm 1490 nm ± 10 nm |
| Isolation | Non-adjacent Channel Isolation: ≥ 40 db |
| Adjacent Channel Isolation: ≥ 30 db | |
| Return Loss | > 50 db |
| Polarization Dispersion Loss | < 0.10 db |
| Polarization Mode Dispersion | < 0.10 ps |
| Specification | RoHS, SGS |
| Centre Wavelength | 1310/1550nm CWDM |
| Pass Channel Wavelength Range | 1550 nm |
| Directivity | ≥50 db |
| Max Power Handling | 300 mw |
| Fiber Type | SMF-28 e, 0.0787 in (2.0 mm) Loose Tube |
| 0.2 cm (2.0 mm) Loose Tube Color | Yellow |
| 0.2 cm (2.0 mm) Loose Tube Length | Customized |
| Connector Type | Customized |
| Connector Color | Customized |
| Insertion Loss Temperature Sensitivity | 0.00278 db/°F (<0.005 db/°C) |
| Operating Temperature | -4 °F to 158 °F (-20 °C to +70 °C) |
| Storage Temperature | -40 °F to 185 °F (-40 °C to +85 °C) |
