Description
Features
- NB-IoT connectivity for remote tracking
- Bluetooth 5.0 with iBeacon support
- Supports MQTT and HTTP protocols
- Compact and durable anti-UV housing
Technical Specifications
| Function | IoT System |
| Bluetooth Protocol | Bluetooth 5.0 |
| WIFI | Optional, 2.4 GHz, positioning only |
| SIM Card | Nano and eSIM |
| Beacon Access Quantity | Maximum of 15 beacon messages per LoRa |
| Certification | CE, FCC, RCM, BQB |
| Peak Current | Max. 140mA in transmit mode |
| Ingress Protection | IP66 |
| Positioning Precision | 3 metres |
| Encryption | AES128, X509 |
| Battery | Li-SoCl2 19000 mAh x2 |
| Bluetooth Positioning | Approx. 150,000 times |
| Standby Current | 25 μA |
| Max. Current | 300 mA |
| Solar Panel | 3 W |
| Max. Charging Current | 500 mA |
| Charging Rate | Max. 1500 mAh each day |
| Battery Life | 1 month @ 10 s Bluetooth receiving and 60 report intervals |
| Certification | CE, FCC, RCM |
| Operating Temperature | -40 ℉ to +185 ℉ (-40 ℃ to +85 ℃) |
| Weight | 150,000 mg (0.150 kg) |
| Dimensions | 6.30 in × 6.30 in × 2.17 in (160 cm × 160 cm × 55 cm) |
