Description
Features
Mini wireless design attached
- Real-time GPS tracking
- Multi-network compatibility enabled
- Waterproof and durable system
- Power-saving mode enabled
- 4G NB-IoT connectivity
Technical Specifications
| Tracker Color | Black |
| Working Voltage | DC 4.2 V |
| Working Current | 80 mA (DC 4.2V) |
| Sleeping Mode | 20 uA |
| Built in Battery | Rechargeable 4000 mAh |
| Operating Temperature | -13 °F to 167 °F ( -25 ℃ to 75 ℃ ) |
| Operating Humidity | 5% to 95% |
| LED Indicator | Green LED for GPS, Red LED for GSM |
| Power Switch | Built-in battery switch on Mainboard |
| Chipset | SIM7000C |
| Frequency | FDD-LTE: B1/B3/B5/B8, GPRS/EDGE 900/1800 MHz |
| Chipset | Securenet ST1612F |
| Positioning Accuracy | < 5m (95%) |
| Cold Start Time | < 45s (average) |
| Warm Start Time | < 2s (average) |
| GPS Sensitivity | -159 dB |
| GPS Frequency | 1575.42 MHz |
| Tracker Weight | 0.44 lbs (0.2 kg) |
| Tracker Dimension | 3.54 in × 2.36 in × 1.38 in (90 mm × 60 mm × 35 mm) |
