| Theory |
Accelerometer magnetometer gyroscope |
| Package / Case |
Anodic oxidation of magnesium aluminum alloy |
| Output |
NB/GSM automatically adapt |
| Mounting Type |
Horizontally or vertically |
| Type |
3 axis accelerometer + 3 axis magnetometer+3 axis Gyro |
| Output Interface |
Digital Output |
| Voltage – Supply |
4.2 V DC |
| Current – Supply |
1000 mA |
| Resolution (Bits) |
0.0007 |
| Current – Supply (Max) |
1000 mA |
| Frequency |
100 |
| Current |
320 mA |
| Measuring Range |
±30(°) |
| Resolution |
0.0007 |
| Shockproof |
>2000 gravity |
| Wide Temperature |
-40 ℉ to 185 ℉ (-40 ℃ to + 85 ℃) |
| Operating Temperature |
-40 ℉ to 185 ℉ (-40 ℃ to 85 ℃) |
| Size / Dimension |
4.29 in x 2.55 in x 2.08 in (10.9 cm x 6.5 cm x 5.3 cm) |
