Description
Features
- Supports BLE, WiFi, and 4G
- Industrial-grade chipset
- MQTT, HTTP, TCP, and UDP support
- Power over Ethernet (PoE)
- OTA and LAN firmware updates
Technical Specifications
| Chipset | nRF52832 + MT7628 |
| Bluetooth Version | 4.2 or 5.0 |
| WiFi | 2.4 GHz |
| Power Supply | 12 V DC PoE |
| Network | RJ45, WiFi, 4G |
| Communication Protocol | MQTT, HTTP, TCP, UDP, IP |
| Function | Data collection, server upload |
| Firmware Upgrade | OTA, LAN, File |
| Operating Temperature | 14 °F to 122 °F (-10 °C to 50 °C) |
| Weight | 1.1 lb (0.5 kg) |
| Dimensions | 7.1 in x 7.1 in x 2 in (18 cm x 18 cm x 5 cm) |
