Description
Technical Specifications
| Common DC characteristics | Power Supply Voltage | Built in 8500 mAh Li-SOCI2 battery
2.5 V to 3.6 V |
| Working Temperature | -40 °F to 185 °F (-40 °C to 85 °C) | |
| Probe Specifications | Measurement Distance | 0.328 ft to 131.233 ft (0.1 m to 40 m) @ 90% reflectivity
0.328 ft to 44.291 ft (0.1 m to 13.5 m) @ 10% reflectivity |
| Distance Resolution | 0.393 in (1 cm) | |
| Environmental light immunity | 100 klux | |
| Shell Protection Level | IP65 | |
| Light Source | VCSEL | |
| Center wavelength | 850 nm | |
| Field of view Angle | 3° | |
| Shell material | ABS + PC | |
| Line length | 29.52 in (75 cm) | |
| Storage Temperature | -22 °F to 176 °F (-30 °C to 80 °C) | |
| Working Temperature | -4 °F to 140 °F (-20 °C to 60 °C) | |
