| Operating Voltage |
2.9 V to 3.7 V (DC) |
| Average Operating Current |
At sensor detection: ≤15, When NB-IoT data is reported: ≤ 110 mA |
| Standby Current |
≤10 µA |
| Battery Capacity |
13000 mAh (3.6V disposable lithium sub batteries) |
| Battery Life |
5 Years (Based on 2 reports per day and relatively good signal conditions) |
| Testing Cycle |
5 Minutes (Can be set) |
| Sensor Interface |
UART, RS485 optional |
| Plane Range |
25 cm to 200 cm (Supporting DYP-A13-V1.0 module parameters, S is the distance to the measured object) |
| Measuring Accuracy |
±(1+0.3% x S) cm |
| Distance Resolution |
1 mm |
| Measuring Angle |
Φ7.5 cm × 100 cm white PVC@100cm: 20° |
| Temperature Detection Range |
-67 °F to 257 °F ( -55 °C to 125 °C ) |
| Temperature Detection Accuracy |
±3.6 °F ( ±2 °C) |
| Inclination Detection Range |
0 to 180° |
| Wireless Network Standard |
NB-IoT, CAT-M1* |
| Wireless Band |
NB-IoT: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B28/B66/B71/B85, CAT-M1*: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B26/B27/B28/B66/B85 |
| Network Protocol |
TCP/UDP/Http Push /CoAP*/MQTT* |
| Positioning Function |
GPS/Galileo (Optional GLONASS/BDS/QZSS) |
| Positioning Accuracy |
3 m (In open conditions) |
| Waterproof Grade |
IP67 |
| Operating Temperature |
-4 °F to 158 °F ( -20 °C to 70 °C ) |
| Main Body Size |
3.9 in x 2.6 in x 1.9 in (100 mm x 68 mm x 50 mm) |
